Eight bytes in one register

Suppose you want to know whether the next eight bytes of a host are a letter, a digit, -, ., _, or ~. In Ada (opens in a new tab) that is the common case inside can_parse. The answer has to be exact. ./ is not a host. _^ is not a host.

A reasonable function might look as follows.

bool eight_clean(const char* p) {
  for (int i = 0; i < 8; i++) {
    unsigned char c = static_cast<unsigned char>(p[i]);
    if (!((c >= 'a' && c <= 'z') || (c >= '0' && c <= '9') ||
          c == '-' || c == '.' || c == '_' || c == '~')) {
      return false;
    }
  }
  return true;
}

If any byte is wrong we return false. If the loop finishes, we return true. On a real host every byte is fine, so the branch is predicted eight times and we learn nothing until the end.

We already have a 256-byte table for this class. One load per byte. I will come back to it with numbers.

Can we do better?

Eight bytes at a time

Eight bytes fit in a uint64_t, and the arithmetic can run on all of them at once. The technique is called SWAR: SIMD within a register. Lamport described it in 1975 (opens in a new tab) . Daniel’s SWAR posts (opens in a new tab) are the best explanation I know. I used it for a lowercase scan in an earlier post (opens in a new tab) .

Load the bytes with memcpy. It looks expensive. With optimizations on, it is one load.

uint64_t word;
std::memcpy(&word, p, 8);

On this machine the first byte of the string is the low byte of the register. The high bit of each byte, 0x80, is that lane’s flag. A mask of all eight flags is 0x8080808080808080. Multiplying by 0x0101010101010101 copies one byte into every lane. splat('.') is 0x2e2e2e2e2e2e2e2e.

constexpr uint64_t kOnes = 0x0101010101010101ull;
constexpr uint64_t kHigh = 0x8080808080808080ull;

constexpr uint64_t splat(uint8_t b) {
  return kOnes * b;
}

Addition and subtraction then touch every lane. A byte that underflows borrows from the next one.

The same load is how can_parse recognizes https://. Eight byte compares become one integer compare. The constant looks backwards because h is the low byte: 0x68, then t t p s : / /.

uint64_t first8;
std::memcpy(&first8, input, 8);
if (first8 == 0x2f2f3a7370747468ull) {  // "https://"
  authority = 8;
}

http:// is seven bytes. The eighth byte is the start of the host, so mask it off.

if ((first8 & 0x00ffffffffffffffull) == 0x002f2f3a70747468ull) {
  authority = 7;
}

On a big-endian machine we load four bytes and compare them with 0x68747470, which is http in memory order, then check s:// or :// one byte at a time. A path segment of 8 to 16 bytes is the same compare: two loads, XOR, OR, compare with zero. Shorter keys keep the live bytes with a mask. Longer keys stay on memcmp.

On https://example.com/ the byte compares take 1.7 ns and the word compare takes 0.5 ns. The rest of the parse is larger than either. The scheme test no longer has a branch per character.

A range that stays in its lane

The host check needs every lane, and it needs a closed range. The routine we ship turns the high bit on before the subtract. A byte in 0x00–0x7F then cannot borrow from its neighbor. The caller has already rejected any word whose high bits are set.

uint64_t in_range(uint64_t w, uint8_t lo, uint8_t hi) {
  uint64_t ge_lo = (w | kHigh) - splat(lo);
  uint64_t le_hi = (splat(hi) | kHigh) - w;
  return ge_lo & le_hi & kHigh;
}

byte | 0x80 is at least 0x80. The threshold is at most 0x7F. The subtract stays inside the byte. The high bit of (byte | 0x80) - lo stays set when byte >= lo. The high bit of (hi | 0x80) - byte stays set when byte <= hi. AND the two masks.

Let’s walk through a to z:

• 'a' is 0x61. (0x61 | 0x80) - 0x61 is 0x80. (0x7A | 0x80) - 0x61 is 0x99. Both high bits are set.
• The byte just below 'a' is 0x60. 0xE0 - 0x61 is 0x7F. The lower bound is clear.
• The byte just above 'z' is 0x7B. The lower bound is set, and (0x7A | 0x80) - 0x7B is 0x7F. The upper bound is clear.

'/' against the one-byte range . loses on the upper bound. The next lane is untouched. I checked every ASCII byte in every lane, against all six classes, with the neighbors set to m. They matched. Bytes at or above 0x80 are a different function. We return false before this one runs.

A clean word is the OR of the six ranges, and that OR has to equal kHigh.

bool eight_clean_host(const uint8_t* p) {
  uint64_t w;
  std::memcpy(&w, p, 8);
  if ((w & kHigh) != 0) {
    return false;
  }
  uint64_t ok = in_range(w, 'a', 'z') | in_range(w, '0', '9') |
                in_range(w, '-', '-') | in_range(w, '.', '.') |
                in_range(w, '_', '_') | in_range(w, '~', '~');
  return ok == kHigh;
}

The word loop takes multiples of eight. The leftover bytes go through the 256-byte table, one at a time. example.com is 11 bytes: one word, then three loads. The code is in implementation.cpp (opens in a new tab) .

Has-zero accepts ./

The formula I tried first is the usual one. Alan Mycroft’s has-zero, from 1987, as written up in Bit Twiddling Hacks (opens in a new tab) . XOR the word with the character you hope to find. A lane that became zero sets its high bit.

uint64_t haszero(uint64_t v) {
  return (v - kOnes) & ~v & kHigh;
}

Subtracting one from a zero byte underflows, and the high bit comes on. A byte from 0x01–0x7F stays clear. & ~v drops a byte that already had the high bit set, so 0x80 and 0xFF are not zeros.

The underflow borrows. Take the bytes 0x00, 0x01. As a little-endian word that is 0x0100. Has-zero returns 0x8080 for those two lanes. The 0x00 is a real zero. The 0x01 borrowed, and now it looks like a zero too. A run of 0x01 keeps going. 0x00 0x01 0x01 0x41 lights the first three lanes and stops at 0x41.

The mask is the wrong set of positions. The word-level answer is still right: a false lane only shows up behind a real zero, so “is any byte zero?” does not flip. That is a fine test when you only need the yes or no. It is a bad test for “is every byte one of these characters?”.

. is 0x2E. / is 0x2F, which is . XOR 1. XOR ./ with eight dots and the lanes are 0x00, 0x01. Has-zero lights both. _ and ^ are the same pair. OR one has-zero mask per allowed character, demand that every high bit be set, and both words look clean.

input      after XOR with the matched byte    lanes
./aaaaaa   00 01 4f 4f 4f 4f 4f 4f             80 80 ..
_^aaaaaa   00 01 3e 3e 3e 3e 3e 3e             80 80 ..

The test suite says it in one line. SWAR must not treat ./ or _^ as eight clean host bytes. https://foo_^bar.com/ does not parse. The has-zero version would have let it through.

What the host check costs

Intel Xeon at 2.4 GHz, g++ 13.3, -O3 -march=native. The machine has AVX-512BW, VL, and SSSE3. Median of repeated runs. The buffers are clean: letters and dots, no tab, no byte under a space. The other tables in this post are the same run. The byte loops are the scalar code GCC emits. For these scans it does not vectorize them. The early return is still in the assembly.

At 8 bytes they tie, about 4 ns. At 15 bytes the word loop is 5.7 ns and the table is 7.5 ns. A kilobyte is 3.8 GB/s against 4.4 GB/s, about 15 percent. Six range tests were never going to beat one load from a hot table by a lot. I would keep the table. The word loop is there so foo_^bar stays illegal. Has-zero is a similar speed and accepts it.

A tab is a yes or no

The portable build of the tab scan has no SSSE3 and no NEON. It looks for \t, \n, and \r eight bytes at a time, and it only needs to know that one of them appeared. Has-zero is the right question there. XOR with a splatted tab, newline, and carriage return. OR the three masks. Ask whether the register is nonzero. The positions are never read. The code is in unicode.cpp (opens in a new tab) .

The input is a clean buffer, which is the common URL. At 8 and 15 bytes the SSSE3 column is the byte loop. We only shuffle once the string is at least 16 bytes, so those rows are 5.5 ns and 9.9 ns of scalar code. SWAR is 3.5 ns and 7.1 ns there.

At 32 bytes the shuffle is 2.2 ns and SWAR is 3.5 ns. A kilobyte is 650 ns in the byte loop, 31 ns in SWAR, 26 ns in the shuffle: 1.6 GB/s, 33 GB/s, 39 GB/s. About 20 times the byte loop. The portable word loop and the 16-byte shuffle are in the same range once the string is long.

A short tail is a zeroed register with the live bytes copied in. Zero XOR a tab is a tab, not zero, so the padding does not look like a match. "hello" is five bytes and reports no tab.

A slash is an index

The URL pattern matcher splits a pathname and records the index of every /. A false lane would invent a segment. Has-zero will not do. The scan uses a zero test that does not carry. Keep the low seven bits, add 0x7F, and the high bit comes on exactly when those seven bits were not zero. 0x7F + 0x7F is 0xFE, so nothing spills into the next byte. OR the original byte, so a value at or above 0x80 counts as nonzero too. OR 0x7F, then invert. The only bit that can still be set is the high bit, and it is set only when the byte was 0x00.

constexpr uint64_t kLow7 = 0x7F7F7F7F7F7F7F7Full;

uint64_t zero_lanes(uint64_t x) {
  return ~(((x & kLow7) + kLow7) | x | kLow7);
}

XOR the word with eight slashes first, so a / is the zero we look for. countr_zero of that mask, shifted down by 3, is the byte index inside the window. lanes &= lanes - 1 clears the lowest set bit and walks the rest. I checked every byte value in every lane. The bit is set only for zero.

The tail is one to seven bytes, gathered into a zeroed register. A zero pad XOR / is 0x2F, which is not zero, so the pad is not a segment. We never read past the end of the string. The scan is scan_segments_swar in the pattern-list header (opens in a new tab) .

On AArch64 a pathname of 16 bytes or more takes the NEON compare. The comment on that function says it is faster at every length they measured, and three to four times faster past a kilobyte. I did not retime it. On this Xeon the SSE2 compare is the same shape.

At 32 bytes with nothing to record, SWAR is 6.1 ns and SSE2 is 9.6 ns. At a kilobyte with nothing to record, SSE2 is 25 GB/s and SWAR is 9.9 GB/s, about 2.5 times. A slash every 16 bytes slows both of them down, because every hit writes an index. That column is 7.7 GB/s and 12 GB/s. The byte loop stays near 1.9 GB/s either way. SWAR is what the portable build runs, and what the short paths run on every machine.

Bytes under a space

A wildcard tail in the same matcher may contain a tab. It may not contain a newline. The filter is has-less (opens in a new tab) : subtract a splatted threshold and keep the high bits that underflowed.

uint64_t hasless(uint64_t v, uint8_t n) {
  return (v - splat(n)) & ~v & kHigh;
}

The borrow is the same one. A byte that really is under 0x20 can light the next lane when that next byte equals the threshold. 0x00 followed by a space lights both lanes. 0x00 followed by 0x21 lights only the first. Every byte under 0x20, followed by a space, does this. I checked every pair, with the other lanes filled with spaces. “Is any byte under the threshold?” was right in all of them.

That is the question the tail asks. A clear mask means there is no newline, and we accept. A set mask falls through to a byte loop that looks for \n and \r only. A tab is under the space character, so it takes the slow path and is then allowed. The fast path is a tail with no controls at all.

The bytes past the end are filled with spaces, not zeros. Zero is under 0x20 and would look like a hit. The slash scan wanted the opposite pad. The pad is part of the test. The function is wildcard_tail_ok in url_pattern_list.cpp (opens in a new tab) .

On a kilobyte of letters and spaces the byte loop does 3.8 GB/s and this filter does 56 GB/s. At 8 bytes it is 4.8 ns against 1.8 ns. The body is one subtract and two ANDs, so a single word is already worth it.

Writing A down to a

to_lower_ascii writes the bytes back. A lane is A to Z when adding 128 - 'A' sets the high bit and adding 128 - 'Z' - 1 does not. XOR those two high bits, shift right by 2, and the bit lands on 0x20. XOR that into the original word. A becomes a.

uint64_t lower_word(uint64_t word) {
  uint64_t hi_a = word + splat(128 - 'A');
  uint64_t hi_z = word + splat(128 - 'Z' - 1);
  return word ^ (((hi_a ^ hi_z) & kHigh) >> 2);
}

'A' is 0x41. 0x41 + 0x3F is 0x80. 0x41 + 0x25 is 0x66. One high bit, shifted, is 0x20. 0x41 ^ 0x20 is 'a'. '[' sets both high bits, the XOR is zero, and the byte stays. An ASCII byte plus 0x3F never carries out of its lane. 0x7F + 0x3F is 0xBE.

I checked every pair of ASCII bytes. They matched. A byte at or above 0x80 can carry. 0xC1 next to @ overflows, the carry sets the high bit of @, and @ becomes 0x60. The function ORs every high bit into a flag and returns false when any lane was outside ASCII. We call it only after the host scan has already kept those bytes out, and only when that scan saw an uppercase letter.

Seven bytes are the wrong length. The byte loop is 5.6 ns and SWAR is 12.5 ns, most of it the tail. At 32 bytes SWAR is ahead, 8.8 ns against 18 ns. A kilobyte is 1.9 GB/s against 46 GB/s.

This is the one loop GCC will vectorize on its own. There is no early return. The same source at -O3 -march=native is an AVX-512 masked update, about 76 GB/s here. The SWAR loop is what we ship when the build cannot ask for that ISA.

What I leave as a byte loop

An IPv4 octet is two or three digits. In the IPv4 post (opens in a new tab) I folded three digits with the weights 1, 10, 100. That was 35 ns per address. The unrolled scalar parser, multiplying by ten as it goes, was 16 ns. SWAR wants a full register. Three digits do not fill one. Keep the * 10.

Percent-encoding is the other one, for a different reason. In the last post (opens in a new tab) the output of a lane was either one byte or three, so there was nothing to store at a fixed width. A 16-byte pshufb finds the bytes that need %XX, and the writes stay scalar. A kilobyte that is almost clean goes from 1.0 GB/s to 9.6 GB/s. A string of spaces gets slower. A uint64_t does not change that.

Which one should you use?

It depends on the question, and on how many bytes you have.

1. One integer compare when the bytes are a fixed prefix such as https://. Write the constant in little-endian order, or memcpy it out of a string and let the compiler do it. Mask the byte you do not have.
2. Has-zero or has-less when you only need to know that some lane matched. The lane after a real hit can light up too. Pad a short word with a byte that fails the test. Zero fails “is this zero?” and “is this under a space?”. It passes “is this a slash?”.
3. The 0x7F add when every match is an index, as with the slashes in a path. A SIMD compare is faster once the string is long and the build can require it. At 32 bytes with nothing to record, the word loop was still ahead.
4. Force the high bit, then subtract, when every ASCII lane needs a closed range. That is the host check. Keep the 256-byte table for the tail. On this machine the table is within about 15 percent of the word loop.
5. The case bit when you are writing A to Z down to a to z and the word is ASCII. Under about 16 bytes, do it one byte at a time. If the compiler is allowed to emit AVX-512, read the assembly before you keep the masks.
6. The byte loop when the group is shorter than a lane. An IPv4 octet is that case.

Compilers will turn a memcpy of eight bytes into one load. They will not notice that ./ is 0x00 then 0x01, and they will not pad a short word with a space instead of a zero.
